ENGINE & GEARBOX

• Engine Description 1262cc, L-Twin Cylinder, Liquid Cooling
• Fuel System Bosch Fuel Injection System, Full Ride-By-Wire System, Øeq 56 Oval Throttle Bodies
• Cooling Liquid Cooling
• Displacement 1262 cc
• Maximum Power 152 HP @ 9500 rpm
• Maximum Torque 126 NM @ 5000 rpm
• Number of Cylinders 2
• Emission Standard Euro 4
• Compression Ratio 13:1
• Bore 106 mm
• Stroke 5 mm
• Valve Clearance Check 30,000km (18,000m)
• Primary drive Straight Cut Gears, Ratio 1.84:1
• Number of Gears 6 Speed
• Clutch Slipper and Self-Servo Wet Multiplate Clutch with Hydraulic Control
• Gear Ratios 1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25
• Final Drive Belt, Front Sprocket Z28, Rear Sprocket Z80

BRAKES & TYRES

• Front Brake 320 mm Twin Semifloating Discs, Radial Brembo Monobloc 4-Piston M4-32 Callipers and Radial Master Cylinder, Bosch Cornering ABS as Standard Equipment
• Rear Brake 265 mm Disc, 2-Piston Floating Calliper, Bosch cornering ABS as Standard Equipment
• ABS Bosch Cornering ABS
• Front Tyre Pirelli Diablo Rosso II, 120/70 ZR17
• Rear Tyre Pirelli Diablo Rosso II 240/45 ZR17
• Front Wheel Light alloy, Cast, 3.5″x17″
• Rear Wheel Light alloy, Cast, 8.00″ x 17″

SUSPENSION & CHASSIS

• Front Suspension Adjustable Ø 50 mm USD Fork
• Rear Suspension Single Shock Absorber, Adjustable Preload and Rebound, Remote Reservoir, Single Sided Swingarm, Cast/Trellis Frame
• Frame Tubular steel Trellis frame
• Exhaust/Muffler Stainless Steel Exhaust and Muffler with Dual Oval Exits, Catalytic Converter and 2 Lambda Probes
• Front Wheel Travel 120mm
• Rear Wheel Travel 110mm

DIMENSIONS & WEIGHT

• Overall Length 2310 mm
• Overall Width 1010 mm
• Overall Height 1133 mm
• Seat Height 755 mm
• Wheelbase 1615 mm
• Dry Weight 220 kg
• Kerb/Wet Weight 247 kg
• Fuel Tank Capacity 18 litres
