ENGINE

• Engine: V4 Granturismo, V4 – 90°,4 valves per cylinder, counterrotating crankshaft, Twin Pulse firing order, liquid cooled
• Displacement: 1,158cc (71cu in)
• Bore X stroke: 83 mm x 53.5 mm
• Compression ratio: 14.0:1
  Maximum power: 168 hp (124kW)@10,750 rpm
• Maximum torque: 12.8 kgm (126 Nm, 93 lb ft) @ 7,500 rpm
• Fuel injection: Electronic fuel injection system, Øeq 46 mm elliptical throttle bodies with Ride-by-Wire system

Transmission

• Gearbox: 6 speed with Ducati Quick Shift up/down
• Primary drive: Ratio 1.80:1
• Ratio: 1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25
• Final drive: Chain, front sprocket Z16, rear sprocket Z43
• Clutch: Hydraulically controlled slipper and self-servo wet multiplate clutch
