THE DUCATI VEHICLE RANGE
MULTISTRADA V2S.
Overview
ENGINE
- Engine Ducati Testastretta,L-Twin cylinder,Desmodromic valvetrain,4 valves per cylinder,Liquid cooled
- Power 113 hp (83kW)@ 9,000 rpm
- Bore x Stroke 94 x 67.5 mm
- Compression Ratio 12.6:1
- Fuel Injection Electronic fuel injection system,Ø 53mm throttle bodies with Ride-by-Wire system
- Starter Electric
- Exhaust Stainless steel single muffler, Catalytic converter and 2 lambda probes
DRIVETRAIN
- Clutch Slipper and self-servo wet multiplate clutch with hydraulic control
- Transmission 6 Speed
- Final Drive Chain Front sprocket 15; Rear sprocket 43
CHASSIS
- Suspension Front Ø 48 mm fully adjustable usd fork
- Suspension Rear Fully adjustable monoshock,Remote spring preload adjustment,Aluminium double-sided swingarm
- Brakes Front 2 x Ø 320 mm aluminum flange semi-floating discs,Radially mounted Brembo monobloc 4-piston 2-pad callipers,Radial Master Cylinder, Cornering ABS
- Brakes Rear Ø 265 mm disc,2-piston Brembo floating calliper,Cornering ABS
- Tires Front Pirelli Scorpion Trail II 120/70 ZR 19
- Tires Rear Pirelli Scorpion Trail II 170/60 ZR 17
- Fuel Tank Capacity 20 l (5.3 US Gal)
- Color Ducati Red” with black rims and tags “Street Grey” livery with black frame and “GP Red” rims
- Dry weight 202 Kg (445 Lb)
- Kerb weight* 225 Kg (496 Lb)
